32 Ways 31dBi X Band Phased Array Antenna For Air Space Surveillance Space Operations

Basic Information
Brand Name: HAITIAN
Certification: ISO
Model Number: X band narrow slotted antenna
Material: Copper Working Frequency: X
Polarization Style: Horizontal Linear Polarization Independent Receiving Channel: 32 Ways
Antenna Gain: 31dBi Beam Width: Azimuth:2.4°pitch:5°
High Light:

32 ways 31dBi X Band Phased Array Antenna

,

32 ways x band antenna array

,

31dBi X band phased array for radar

X Band Phased Array Antenna

Introduction

Multilayer slot antenna is a kind of antenna which open cracks on the metal plate, wave guide, coaxial line, resonant cavity. Electromagnetic wave can pass the cracks to form a Electromagnetic filed. It is very convenient array because of its low section, integrable, workable . It usually have double-deck and multi-deck design to form the antenna array. Mainly used on the wave guide radar, navigation , electronic antagonism, communication equipment and other filed.

Antenna Type

X band narrow slotted antenna

Working frequency

X

Polarization style

Horizontal linear polarization

Independent receiving channel

32 ways

Antenna gain

 31dBi

Beam width

Azimuth:2.4°pitch:5°

Slot side Electric potential

-27dB

32 Ways 31dBi X Band Phased Array Antenna For Air Space Surveillance Space Operations 0
