Material: | Aluminum Copper | Radar Wave Band: | Ku |
---|---|---|---|
Technical System: | DBF | Scan Style: | Azimuth Scan And Pick Frequency Scan |
Detective Distance (UAV Rcs=0.01㎡): | 5KM | Data Rate: | 2.5S(pitch Cover 15°) 5S(pitch Cover 30°) |
High Light: | 5KM Ku Band Phased Array Radar,5KM automotive radar target tracking,5KM phased array tracking radar to intercept on target |
radar YFR-05C-Ⅱ(developing) New technology(DBF) was used on this radar,improve the accuracy,target tracking performance
New technology(DBF) was used on this radar,improve the accuracy,target tracking performance,rate date to new level.
Technical target | YFR-05C-Ⅱ(developing) | |
Radar wave band | Ku | |
Technical system | DBF | |
Scan style | azimuth scan and pick frequency scan | |
Detective distance (UAV rcs=0.01㎡) | 5KM | |
coverage | Pitch:15°/30°azimuth:±360° | |
Detection accuracy
|
Distance | ≤2m |
Detection accuracy Position | ≤0.3° | |
Pitch | ≤0.4° | |
Data rate |
2.5S(pitch cover 15°) 5S(pitch cover 30°) |
|
Number of tracking targets/TAS | ≥200batches | |
Weight | ≤35KG | |
Size | ≤520*324*585(mm) | |
Power waste | ≤700W |
