| Place of Origin: | China |
|---|---|
| Brand Name: | YAOFENG |
| Certification: | ISO |
| Model Number: | YFR-01B |
| Minimum Order Quantity: | 1 |
| Delivery Time: | 1 month |
| Supply Ability: | 10 sets per month |
| Material: | Aluminum Copper | Radar Wave Band: | Ku |
|---|---|---|---|
| Scan Style: | Azimuth Scan And Pick Frequency Scan | Detective Distance (UAV Rcs=0.01㎡): | 3KM -5KM |
| Pitch Coverage: | 0°-40° | Tracking Mode: | TWS |
| High Light: | 3KM aircraft detection Frequency Scan Radar,3KM radar detector ku band,Frequency Scan Radar 3KM |
||
radar YFR-01 (It usually use for locate the low altitude aircraft)
YFR-01B is a kind of azimuth scan and pick frequency scan(Doppler system three coordinates) radar,It usually use for locate the low altitude aircraft.
This radar can detective the position in the space, matching photoelectricity system. It also can connected with disturb, laser weapons, navigation decoy and other counter equipment.
| Technical target | YFR-01B | YFR-01C | |
| Radar wave band | Ku | Ku | |
| Technical system | Linear Frequency Modulated Pulse | Linear Frequency Modulated Pulse | |
| Scan style | azimuth scan and pick frequency scan | azimuth scan and pick frequency scan | |
| Detective distance (UAV rcs=0.01㎡) | 3KM | 5KM | |
| Pitch coverage | 0°-40° | 0°-40° | |
|
Detection accuracy
|
Distance | ≤10m | ≤10m |
| Detection accuracy Position | ≤0.8° | ≤0.6° | |
| Pitch | ≤0.8° | ≤0.5° | |
| Tracking mode | TWS | TWS | |
| Number of tracking targets | ≥200batches | ≥200batches | |
| Weight | ≤25KG | ≤26KG | |
| Size | ≤560*280*470(mm) | ≤610*270*440(mm) | |
| Total power waste | ≤120W | ≤160W | |
