| Place of Origin: | Hefei China |
|---|---|
| Brand Name: | HAITIAN |
| Model Number: | 03 |
| Minimum Order Quantity: | 10 |
| Material: | Aluminum | Frequency Range: | 100MHZ-10GHZ |
|---|---|---|---|
| Level Control: | TTL | Working Frequency (GHz): | 40-70 |
| Insert Loss (dB): | -4.5 | Stopband Frequency (GHz): | 30,≥30dB 80,≥30dB |
| High Light: | 20 db directional coupler,10 db directional coupler design,30 db directional coupler |
||
switch wave filter series wave guide harmonic filter
frequency range: 100MHZ-10GHZ
TTL level control
switch speed fast
can order
| Type |
Working frequency (GHz) |
Insert loss (dB) |
Stopband frequency (GHz) |
VSWR |
| 1 | 40-70 | -4.5 |
30,≥30dB 80,≥30dB |
2.0:1 |
| 2 | 60-100 | -4.5 |
50,≥30dB 110,≥30dB |
|
| 3 | 90-140 | -5.0 |
80,≥25dB 150,≥25dB |
|
| 4 | 130-200 | -5.0 |
120,≥25dB 210,≥25dB |
|
| 5 | 190-210 | -6.0 |
180,≥25dB 220,≥25dB |
|
| 6 | 200-280 | -5.0 |
180,≥25dB 300,≥25dB |
|
| 7 | 270-360 | -4.5 |
250,≥25dB 380,≥25dB |
|
| 8 | 40-360 | -4.5 |
30,≥30dB 400,≥30dB |
|
| 9 | 590-620 | -5.5 |
550,≥45dB 650,≥45dB |
1.5:1 |
| 10 | 480-735 | -4.5 |
350,≥55dB 850,≥55dB |
|
| 11 | 690-735 | -5.5 |
620,≥50dB 850,≥55dB |
